The AV500 home cinema power amp is a 5-channel model developing up to 85 watts per channel into 8 ohms. Equipped with high quality electronic components, this amplifier will be advantageously associated with an integrated home cinema amplifier with pre-out outputs, in order to amplify the front and surround channels. This very musical amp, combining power and finesse, allows the listener to dive into the heart of the action.

OVERVIEW

The ATOLL AV500 is a powerful five-channel amplifier that delivers 85 watts of power per channel, making it an excellent choice for home theater systems. It features high-quality components, precise engineering, and a sleek, modern design, making it a popular option for audiophiles and home theater enthusiasts.

FEATURES

• 4 mm brushed aluminium front.
• 1,5 mm steel frame.
• 2×100 Wrms under 8 Ω, 5×85 Wrms under 8 Ω.
• 2 toroidal transformers of 340 VA each.
• Total Capacitive: 73 000 µF.
• Symmetrical stages with discrete components.
• MOS-FET technology output transistors.

SPECIFICATIONS

• Power in Wrms / 8 Ω (230 V): 5×85 W / 2×100 W
• Power in Wrms / 4 Ω (230 V): 5×100 W / 2×140 W
• Power supply: 2×340VA
• Total of capacitors: 73,000 µF
• Number of entries: 2×5
• Input impedance: 47 kΩ
• Sensitivity: 1,58 V to 1,77 V
• Signal/Noise ratio: 100 dB
• Distortion at 1 kHz: 0,005%
• Bandwidth: 5 Hz – 200 kHz
• Rising time: 1,3 µs
• Dimensions: 440×291×95 mm
• Weight: 12 Kg
